Product properties
Connection diagram
MosBus Energy Meter Configuration
All registers are available for reading via Modbus RTU and TCP. The registers are read-only, except for the specifically mentioned registers (5026 and 11000+).
Factory settings
Slave Address: 1
Baud Rate: 19200
Parity Stop Bits: 1
Data Bits: 8
Factory settings
Slave Address: 1
Baud Rate: 19200
Parity Stop Bits: 1
Data Bits: 8
Measurements on the LoRa electricity meter
- Active power (kW)
- Reactive power (kvar)
- Apparent power (kVA)
- Current (A)
- Consumption of active energy (kWh) and delivery (kWh)
- Reactive energy consumption (kvarh) and delivery (kvarh)
- Frequency (Hz)
- Number of power interruptions
S0 pulse output
In addition to the LoRa radio interface, the EMU Professional II energy meter has a configurable S0 pulse output.
- Active energy consumption or active energy supply
- Reactive energy consumption or reactive energy supply
Factory configuration with direct connection: 1,000 pulses/ kWh, 40 ms
Rate Control
Rate switching occurs by connecting 230VAC to the corresponding terminal.
0 = no voltage; 1 = 230VAC,
Dimensions
